ADATA DIMM DDR4 4GB 2666MHz CL19 512x8 Premier, Retail
ADATA Premier DDR4 2666 unbuffered-DIMM memory is the latest upgrade solution that supports Intel's newest platforms for faster data transfer and enhanced power efficiency. Utilizing a 288-pin design, operating voltage has been reduced from 1.5V on DDR3 to 1.2V, which not only helps save power by 20%, but also boosts transfer bandwidth speed to 21.3GB/s. Every chip in ADATA memory modules meets strict JEDEC and RoHS standards, ensuring compatibility, stability, and environmentally friendly products.
Lightning speed PCIe Gen3x4
- Complies with JEDEC standards
- RoHS compliant
- Supports Intel Skylake-X and Kaby Lake-X CPU
Lifetime Warranty
All ADATA memory modules are produced and tested using a rigorous quality control process for rapid computing and stable operation. In addition, ADATA memory modules provide customers a lifetime warranty for maximum assurance with excellent service.
TECHNICAL SPECIFICATIONS
| PN | AD4U266638G19-R |
| Module Type | U-DIMM |
| Form Factor | Standard 1.23" height |
| Memory Type | DDR4 |
| Standard | JEDEC |
| Interface | 288-pin |
| Density | 8GB |
| Speed | 2666MHz |
| Power supply | VDD and VDDQ = 1.2V±0.06V |
| DRAM activation power supply | VPP= 2.5V (+0.25V / -0.125V) |
| DRAM spec/VCC | DDR4 STD 1.2V |
| Operating temperature | 0 - 85°C |
| Warranty | Lifetime |
.
